Copper, Flexible, XLPE Insulated and LSZH Sheathed Non halogenated Control Cable – Safetymax Control_
Used in command, control and signaling circuits, in industrial, comercial installations, power plants, substations, control of machinery and equipment in general.
Product Info
Insulation:
In thermoset HEPR 90°C polyolefin compound, halogen-free, with special characteristics of low smoke emission.
Sheath:
Thermoplastic polyolefin compound, halogen-free, black in color, with special characteristics for non-propagation, selfextinguishing fire, and low smoke emission.
Identification:
Black numbered cores + one green/yellow core and black outer sheath
Voltage:
- 1,00 mm²: 500V
- 1,50 to 10,00 mm²: 1 kV
Maximum Operational Temperatures:
- 70° in continuous operation
- 100° in overload
- 160° in short circuit
Conductor:
Formed by electrolytic bare copper wires, soft temper, stranding class 4 (1,00 a 6,00 mm²) and class 5(10,00 untill 300,00 mm²).
Applicable Standards:
- ICEA T-26-465: Standard for 600-Volt to 2000-Volt Power Cables
- NEMA WC-54: Standard for Thermoset Insulated Wire and Cable
- NEMA WC-7: Standard for Cross-Linked-Thermosetting-Polyethylene-Insulated Wire and Cable for the Transmission and Distribution of Electrical Energy
- IEC 60754-2: Test on Gases Evolved during Combustion of Materials from Cables – Part 2: Determination of the Amount of Halogen Acid Gas
- ASTM B3: Standard Specification for Hard-Drawn Copper Wire
- ASTM B8: Standard Specification for Concentric-Lay-Stranded Copper Conductors
